Ideal for Municipalities and Rental Stores.
Jackshaft Design = Full Torque
14”-30” Blade CapacityGreat mid-size saw for service, utility work and rental
Jack shaft allows full engine power
Easy to maneuver self propelled drive
Engine adjustment mechanism for belt tightening and maintenance
Strongest frame on the market
30% more torque with new jack shaft design (on gas models)
Fits through a 30” door frame
Specifications:
| Maximum depth of cut with 14” blade: | 4-3/8” |
| Maximum depth of cut with 20” blade: | 7-3/8” |
| Maximum depth of cut with 26” blade: | 10-3/8” |
| Maximum depth of cut with 30” blade: | 2-3/8” |
| Blade shaft diameter: | 1-3/4” |
| Arbor size: | 1” w/drive pin |
| Blade shaft drive: | 6 belt |
| Blade mounting: | Right or Left |
| Blade raise & lower: | Electro-hydraulic pump |
| Transmission: | Eaton Model 10 |
| Drive speed: | 0-200 feet/min |
| Air filter: | 4 stage |
| Fuel capacity (gas models): | 6 gallons |
INCLUDES: Telescoping front pointer, Cutting depth indicator, Quick disconnect blade flanges, Hour meter, Frame lift.
